74ABT2244
Octal Buffer/Line Driver with
25
Series Resistors in the Outputs

General Description
The ABT2244 is an octal buffer AND line driver designed to drive the capacitive inputs of MOS memory drivers, address drivers, clock drivers, AND bus-oriented transmitters/ receivers.
The 25: series resistors in the outputs reduce ringing AND eliminate the need for external resistors.

Features

•
  Guaranteed latchup protection
•
  High impedance glitch-free bus loading during entire power up AND power down cycle
•
  Nondestructive hot insertion capability

Ordering Code:
Devices are also available in Tape AND Reel. Specify by appending the suffix letter “X” to the ordering code.
Pb-Free package per JEDEC J-STD-020B.
Connection Diagram
Schematic of Each Output
Pin Descriptions
Truth Table
H HIGH Voltage Level
L LOW Voltage Level
X Immaterial
Z High Impedance
