■ TIP141, TIP142, TIP145 AND TIP147 ARE STMicroelectronics PREFERRED SALESTYPES

■ COMPLEMENTARY PNP - NPN DEVICES

■ MONOLITHIC DARLINGTON CONFIGURATION

■ INTEGRATED ANTIPARALLEL COLLECTOR-EMITTER DIODE

APPLICATIONS

■ LINEAR AND SWITCHING INDUSTRIAL EQUIPMENT

DESCRIPTION

The TIP140, TIP141 AND TIP142 are silicon Epitaxial-Base NPN power transistors in monolithic Darlington configuration, mounted in TO-218 plastic package. They are intented for use in power linear AND switching applications.

The complementary PNP types are TIP145, TIP146 AND TIP147 respectively.
