15-V Digital OR ±7.5-V Peak-to-Peak Switching

125-Ω Typical On-State Resistance for 15-V Operation

Switch On-State Resistance Matched to Within 5 Ω Over 15-V Signal-Input Range

On-State Resistance Flat Over Full Peak-to-Peak Signal Range

High On/Off Output-Voltage Ratio: 80 dB Typical at fis = 10 kHz, RL = 1 kΩ

High Degree of Linearity: <0.5% Distortion Typical at fis = 1 kHz, Vis = 5 V p-p, VDD – VSS ≥ 10 V, RL = 10 kΩ

Extremely Low Off-State Switch Leakage, Resulting in Very Low Offset Current AND High Effective Off-State Resistance: 10 pA Typical at VDD – VSS = 10 V, TA = 25°C

Extremely High Control Input Impedance (Control Circuit Isolated From Signal Circuit): 1012 Ω Typical

Low Crosstalk Between Switches: –50 dB Typical at fis = 8 MHz, RL = 1 kΩ
